1. General
JCL/CLQ series marine or centrifugal fans (simply the fans) are capable of blowing air, such as ocean air containing salt vapor and corrosive air containing a small quantity of oil vapor. They are suitable for cabin air ventilation and exchange on oceangoing vessels. They are also applicable in other places that suit.
The fan is designed and manufactured according to the standard of GB11864-2008《Marine Centrifugal Fans》 and 《The manufacture Rules of Sea-going Steel Ships 》 which approved by the Register of the People’s Republic of China.
This series fans have been examined and proved up to standard by the Explosion-proof Inspection Authority of the PRC and have got the certificate of inspection. They have also been examined by the register of shipping of RC and have got the certificate.
2. Features
Small in size and light in weight. Low noise and low vibration. Good anti-corrosiveness. Good air tightness.
Small starting torque. Strong performance of resisting swing, vibration and shock
3. Structural
The ventilator is designed and manufactured into a horizontal structure type or a vertical one. Which the vane wheel is mounted directly on the motor shaft extension.
The vane wheel, being riveting structure is made of aluminum alloy and carefully balanced by static and dynamic ways.
Both the casing and the inlet are made of welded common steel with airtight structure.
4. Model explanation
