CLZ TYPE Marine Vertical Self-Priming Centrifugal pump

Category:Engine Equipment
Certificate:ABS,LR,BV,DNVGL,NK,KR,IRS,RMRS,CCS
FOB Price:Get Latest Price Now
Quality Guarantee:12 Months unless specified otherwise
Place of Origin:China

Request a Quote

Get a factory quote now, we can supply according to your requirement.

China CLZ TYPE Marine Vertical Self-Priming Centrifugal pump Introduction:

Specifications

Brand Name

HS Code

8413709990

Unit

SET(Sets)

Customed Made

MOQ

Delivery Period

15 days

Description

CLZ TYPE Marine Vertical Self-Priming Centrifugal pump

General Description:

The CLZ type marine vertical self-priming pumps is a new type patented product. CLZ pump is of small body, good self-priming performance, light weight and easy installtion and operation.

This product is used for under cabin pump, pressure pump, fire-fighting pump, cooling pump and matching with other device. The temperature of sea water or fresh water should be below 80 degree C.

It can be alter for dredge pump if necessary. The big standar pumps of this type can be water cannon for suppress smuggling and working pump complemented fire-fighting cannnon.

The marks of Pump(for example):

65CLZ-4

65 - suction diameter(mm)

C - marine centrifugal pump

L - Vertical

Z - Self-priming

4 - integer: specific speed divided by 10.

Parameter

Model	Flow rate	Head	Speed	Npshr	Suction head	Shaft power	Motor power	Efficiency
	m3/h	m	rpm	m	m	kw	kw	%
40CLZ-2	5	60	2900	3.5	6.5	3.93	5.5	19
50CLZ-3	12.5	50	2900	3.2	6.8	3.27	5.5	52
50CLZ-4.5	12.5	32	2900	3.2	6.8	2.53	4	43
50CLZ-4.5A	10	28	2900	3.2	6.8	1.8	3	43
50CLZ-6	20	32	2900	3.2	6.8	3.23	4	54
50CLZ-6A	17	28	2900	3.2	6.8	2.49	4	52
50CLZ-4	20	50	2900	3.2	6.8	5.45	7.5	50
50CLZ-4A	17	46	2900	3.2	6.8	4.44	7.5	48
50CLZ-9	27	14.5	2900	3.2	6.8	2.54	3	42
65CLZ-5	25	45	2900	3.2	6.8	6.38	7.5	48
65CLZ-4.5	25	60	2900	3.2	6.8	8.33	11	49
65CLZ-3	25	80	2900	3.2	6.8	11.1	15	49
65CLZ-9	25	20	2900	3.2	6.8	3.24	4	42
65CLZ-6	25	32	2900	3.2	6.8	4.19	5.5	52
65CLZ-6A	21	28	2900	3.2	6.8	3.14	4	51
65CLZ-8	35	32	2900	3.2	6.8	5.55	7.5	55
65CLZ-8A	32	28	2900	3.2	6.8	4.52	5.5	54
65CLZ-5.5	35	50	2900	3.2	6.8	9.53	15	50
65CLZ-5.5A	30	48	2900	3.2	6.8	8.17	11	48
65CLZ-4	35	70	2900	3.2	6.8	13.9	22	48
65CLZ-4A	32	65	2900	3.2	6.8	12.1	15	47
80CLZ-13	45	21	2900	3.5	6.5	5.14	7.5	50
80CLZ-11	50	25	2900	3.5	6.5	7.09	7.5	48
80CLZ-7.5	60	50	2900	3.5	6.5	17.7	22	46
80CLZ-5	60	80	2900	3.5	6.5	22.5	30	58
80CLZ-9	50	32	2900	3.5	6.5	7.03	11	62
80CLZ-9A	45	28	2900	3.5	6.5	5.6	7.5	61
80CLZ-9B	54	21	2900	3.5	6.5	5.1	7.5	60
80CLZ-6	50	50	2900	3.5	6.5	11.7	15	58
80CLZ-6A	45	48	2900	3.5	6.5	10.3	15	57
80CLZ-4	50	80	2900	3.5	6.5	21.8	30	50
80CLZ-4A	50	70	2900	3.5	6.5	19.5	22	49
80CLZ-4B	45	62	2900	3.5	6.5	16.2	18.5	47
80CLZ-3	50	120	2900	3.5	6.5	35.5	45	46
80CLZ-3A	45	110	2900	3.5	6.5	29.3	37	46
100CLZ-17	80	20	2900	4	6	7.26	11	60
100CLZ-12	80	32	2900	4	6	11.6	15	60
100CLZ-12A	72	20	2900	4	6	9.3	15	59
100CLZ-8	80	50	2900	4	6	18.8	22	58
100CLZ-8A	72	46	2900	4	6	15.8	18.5	57
100CLZ-6	80	80	2900	4	6	34.2	37	51
100CLZ-6A	72	75	2900	4.5	5.5	29.4	37	50
100CLZ-6B	75	62	2900	4.5	5.5	26.4	30	48
100CLZ-18.5	100	20	2900	4.8	5.2	9.1	11	60
100CLZ-18.5A	95	18	2900	4.8	5.2	8.03	11	58
100CLZ-13	100	32	2900	4.8	5.2	13.8	18.5	63
100CLZ-13A	95	28	2900	4.8	5.2	11.7	15	62
100CLZ-9	100	50	2900	4.5	5.5	22	30	62
100CLZ-9A	95	46	2900	4.5	5.5	19.5	22	61
100CLZ-6.5	100	80	2900	4.5	5.5	39.6	45	55
100CLZ-6.5A	95	75	2900	4.5	5.5	35.9	45	54
100CLZ-5	100	120	2900	4.5	5.5	62.8	75	52
100CLZ-5A	95	110	2900	4.5	5.5	55.8	75	51
125CLZ-5	120	120	2900	5	5	76.8	90	51
125CLZ-9	200	80	2900	5.2	4.8	75.1	90	58
125CLZ-23.5	160	20	2900	5.2	4.8	13.4	18.5	65
125CLZ-23.5A	150	18	2900	5.2	4.8	11.5	15	64
125CLZ-16.5	160	32	2900	5.2	4.8	22.1	30	63
125CLZ-16.5A	150	28	2900	5.2	4.8	18.4	22	62
125CLZ-12	160	50	2900	5.2	4.8	35.1	45	62
125CLZ-12A	150	46	2900	5.2	4.8	30.8	37	61
125CLZ-8	160	80	2900	5.2	4.8	60.1	75	58
125CLZ-8A	150	75	2900	5.2	4.8	52.8	75	58
125CLZ-8B	150	68	2900	5.2	4.8	48.7	55	57
125CLZ-6	160	120	2900	5.2	4.8	95.1	110	55
125CLZ-6A	150	110	2900	5.2	4.8	83.2	110	54
150CLZ-21	250	32	2900	6	4	33.5	45	65
150CLZ-21A	240	28	2900	6	4	28.2	37	65
150CLZ-14	250	50	2900	6	4	53.2	75	64
150CLZ-14A	240	46	2900	6	4	47.7	55	63
200CLZ-12	300	30	2900	5.5	4.5	40.9	45	60
200CLZ-12A	280	25	2900	5.5	4.5	32.9	37	58
200CLZ-24.5	450	15	2900	6	4	34.04	37	54
200CLZ-19	300	30	2900	6	4	36.3	45	60
200CLZ-19A	300	30	2900	5.5	4.5	40.8	55	60
200CLZ-20.5	500	20	2900	6	4	43.9	55	62

Main parts Materials

Names	Material
	Names	Shop sign	Specimens	Remark
Pump body, pump cover, in/out flange, impeller cover plate, centrifugal chamber	Silicon brass	ZCuZn16Si4	GB1176-87	Sea water
	Cast iron	HT200	GB9437-88	Fresh water
Impeller, seal ring	Silicon brass	ZCuZn16Si4	GB1176-87
