1. Twin capstan, single gypsy, twin gypsy available.
2. Reversible motor.
3. Independent operation of capstans and gypsy by declutching the drive.
4. Simple deck mounted installtion with no under deck parts.
5. Simplified maintenance with ability to strip the running gear from the windlass without disturbing the windlass mounting.
6. Totally sealed gearbox with ground worm drive.
7. Horizontal windlass casing are cast marine grade aluminium alloy with white epoxy enamel finish.
8. Fit include hand-switch, control box and wrence.
|
Model
|
Weight |
Power
|
Motor |
No load |
Max |
Max. |
Line |
Rope |
Chain |
|
net(kg) |
(W) |
absorption |
Load |
Pull |
Speed |
Size |
Size |
||
|
YDH-011 |
16 |
12V/24V |
600 |
50A |
190kg |
600kg |
30m/min |
12-14mm |
6-7mm |
|
YDH-012 |
25.2 |
12V/24V |
1000 |
90A |
350kg |
750kg |
25m/min |
14-16mm |
8-10mm |
|
YDH-013 |
32 |
12V/24V |
1400 |
125A |
520kg |
1100kg |
25m/min |
18-20mm |
8-10mm |
|
YDH-014 |
33.7 |
12V/24V |
1600 |
140A |
660kg |
1400kg |
20m/min |
20-24mm |
10-12mm |
|
YDH-015 |
36 |
220V/380V |
2000 |
6A |
900kg |
2000kg |
20m/min |
20-24mm |
10-13mm |
|
YDH-016 |
38 |
220V/380V |
3000 |
9A |
1200kg |
2500kg |
20m/min |
20-24mm |
10-13mm |
Welcome to consult China Horizontal Windlass suppliers. We have more than 10 years of foreign trade supply experience and have provided high-quality shipping equipment to dozens of countries around the world. We provide you with high-quality services and preferential prices customized by manufacturers. You can get a free quote online or leave a message below and we will reply to you within 24 hours.
