The inclined belt skimmer is mainly composed of the hydraulic power station, skimming head(main unit), hydraulic oil hose, oil pipeline and other parts.
the main unit of the skimmer pushes the oil spills on the water surface down into the water through the loop-shaped tape which declines downward and then the oil rises up and floats in the oil collecting channel so that the oil spills are gathered and pumped away. One end of the inclined belt is above the water surface while another end is below the water surface in the oil collecting channel. It is driven by the hydraulic motor and hence the oil it encounters is continuously pressed down to the bottom of the channel and then the oil will rise up again and float in the oil collecting channel due to its specific gravity less than water.
The power station operates with hydraulic oil pump and oil delivery pump driven by the diesel engine or motor; the main unit is composed of the inclined belt roller unit, the oil collecting channel, frame, buoy, the hydraulic oil hose, oil pipeline and other parts. The main unit is located on the water surface while the power station is set on the boat or shore.
This product is not only suitable for harbors, wharfs, gulf, rivers, lakes and other semi-enclosed waters, but also for open seas, offshore and other open waters.
Oil spills can be recovered to a high purity, up to 99%.
The floating oil spills with various viscosities can be recovered.
Oil spills, thick or thin, can be recovered efficiently with the recovery rate up to 99%. It has overcome the shortcomings of other types of skimmers, which can not recover thin slicks.
It can operate in conjunction with the containment boom for oil sweeping at a forward speed up to 3knot.
It can operate with certain stormy waves at a certain flowrate.
It is easy to operate. Only a few operators are required. It can meet the requirements for rapid response to an emergency.
Easier maintenance and long service life.
In addition to the features of an inclined belt skimmer, the multi-function skimmer has the function of recovering floating wastes and spilled oil sludges.
| Model | XDJ-10 | XDJ-20 | XDJ-30 | XDJ-40 | XDJ-60 | XDJ-100 | XDJ-200 |
| Max.Skimming rate(m3/h) | 10 | 20 | 30 | 40 | 60 | 100 | 200 |
| Working pressure(MPA) | 3~6 | 3~6 | 5~6 | 5~6 | 5~8 | 5~10 | 5~10 |
| Driving power(Kw) | 6.3 | 14.5 | 14.5 | 21 | 21 | 29 | 56 |
| Suction head of pump(m) | 8 | ||||||
| Lift of pump(m) | 15 | 30 | 30 | 30 | 30 | 30 | 30 |
| No of diversion booms(piece) | 2 | ||||||
| Length os diversion booms(m) | 6 | 6 | 6 | 10 | 10 | 10 | 10 |
| Length of boom arm(m) | 6 | 6 | 6 | 10 | 10 | 10 | 10 |
