China IP Intelligent Laser Introduction:
Specifications
Brand Name
HS Code
Unit
Customed Made
Yes
MOQ
0
Delivery Period
--
Description
1、First, leading technology •Intelligent laser excited, radio frequency (rf) The only domestic rf high power intelligent laser excited Through optical valley, so the years of research and development of laser engineering and technical personnel, commercial rf high power intelligent laser excited. The synchronous technology with the international most advanced technology, reached the international advanced level, making China a high-power radio frequency laser producer except Germany, filled the domestic blank. •Intelligent control system The industry's only intelligent control system Through optical valley too laser control system of intelligent control, greatly exert the potential of the NT series intelligent laser, combined with the laser processing parameters subroutine functions not only make the operation more simple, and expanded the scope of use, improve the processing efficiency and performance, reduces the use cost •Modulation, the outstanding performance NT - RF series intelligent laser with RF excitation, so greatly improve the performance of modulation, frequency modulation for 10 to 20 KHZ, is ordinary laser 10 times, greatly improve the ability of laser cutting thin plate. •intelligent laser output power slope When laser cutting plate or welding, need for slope, laser power output is slowly climb, slow down. Through the optical valley too laser intelligent control system control, NT series intelligent laser according to actual processing demand, output different climbing time and fall time of laser power output waveform, in order to meet the processing requirements. •the external rf low voltage electrode to eliminate pollution NT - RF series intelligent laser electrode on the outside of the cavity, thus to eliminate the pollution of cavity, greatly extend the service life of the optical lens, greatly reduces the customer cost of using low-pressure trigger electrode to eliminate high voltage insulation. •The laser power output sawtooth wave, intelligence In laser cutting thin plate Angle and small round or welding, the need for laser power output sawtooth wave, in order to reduce heat affected zone. Through optical valley too laser intelligent control system control, NT series intelligent laser according to actual processing demand, output of different frequencies, different power range of laser power output waveform, in order to satisfy the demands of laser processing. •intelligent laser power inverter output Laser pulse are required for cutting thick plate perforation. Through optical valley too laser intelligent control system control, NT series intelligent laser can, according to the different frequency of laser pulse output, improve the efficiency of punching, with CNC machine to variable frequency zoom perforation, to meet the requirements of laser processing. •laser output high quality base model NT series intelligent laser after years of research and development, the optimization design of laser resonator, USES the international top-level infrared optical lenses, makes the output of a laser beam mode to TEM00, far better than the ordinary laser TEM01 and TEM10. • intelligent high speed laser output Laser in use process, because the cutting material and thickness is different, the laser output needed to response time is not the same, through the optical valley too laser intelligent control system control, NT series intelligent laser according to actual processing requirements, the output laser at high speed, to meet the requirements of laser processing, the response time of 20 ~ 50 us, 50-100 times that of ordinary laser. • advanced optical path compensation design NT series intelligent laser after years of research and development, using international advanced optical path optimization plastic technology, makes the output of the laser spot diameter greater than 25 mm, no change and maintain 8 m scope, improve the laser beam is focused on the performance, and makes a wide range of cutting without equipped with constant light path system, not only improves the machining efficiency, and reduced the configuration of nc machine tools, reduce the cost of the user •smart standby When the laser does not work or work for a long time interval is longer than the other, through the optical valley too laser intelligent control systems and control, make the NT series laser to enter standby mode, and reduces the power consumption of the laser and the working gas consumption; Enter the standby mode, laser power consumption is only < 1 kw/hour, working gas consumption of only 0.1 L/h, conversion of only 1.1 yuan/hour; Only one key to return to work. •Intelligent air supply Laser in use process, because of the different cutting materials and thickness, required to have different laser power, no matter how much power is ordinary laser laser working gas consumption is constant; Through the optical valley too laser intelligent control system control, NT series intelligent laser according to actual use laser power automatically adjust the laser working gas consumption, avoid unnecessary waste. •more straight cold technology Laser will produce a lot of heat in the process of work, NT series intelligent laser after years of research and development, the exclusive use of the international most advanced laser industry in China more straight cold technology, direct cooling to heating source, not only reduce the volume of the laser, and reduced the demand for cold water machine the capacity, so the user the acquisition cost greatly reduced. •Ultra high photoelectric conversion efficiency The adoption of international most advanced multi-point straight cold technology, greatly improve the heat exchange efficiency, reduce unnecessary waste, make the NT series laser with high photoelectric conversion efficiency of 24%, 2 times that of ordinary laser, thereby saving the user's electricity cost, power consumption is only 60% of the average laser. •maglev gas circulation system NT - RT series intelligent laser adopts maglev turbo fan for gas circulation center, without oil lubrication, so comprehensively to eliminate pollution, greatly extend the service life of the gas cycle parts, greatly reduces the customer's use. •Strong, steady flow pulse of humanity NT series intelligent laser after years of research and development, through the adoption of international most advanced multi-point straight cold technology, greatly improve the heat exchange efficiency, improve the stability of cavity, so that the super pulse and stable operation, not only can be used for pulse punch, but also to pulse fine sheet cutting. •unique gas ratio For He, N2, CO2 gas laser work, in which He consumption and the highest price. NT series laser after years of research and development, through the adoption of international most advanced multi-point straight cold technology, greatly improve the efficiency of heat exchange, reduced the dependence on He cooling effectiveness, will change laser gas ratio of 50% : 45% : 5%, greatly reduces the operating cost of users, gas cost is only 70% of the average laser.
2、Processing Ability
laser
The material
Auxiliary gas
The maximum thickness (mm)
1000W
Carbon steel SS400)
oxygen
5~7
High pressure air
High pressure nitrogen
Stainless steel (SUS304)
oxygen
3~5
High pressure air
High pressure nitrogen
A5052
Standard air
High pressure air
High pressure nitrogen
Nonmetal
Standard air
19~22
1500W
SS400
oxygen
11~15
High pressure air
3~4
High pressure nitrogen
3~4
SUS304
oxygen
7~8
High pressure air
4~5
High pressure nitrogen
2~3
A5052
Standard air
3~4
High pressure air
5~6
High pressure nitrogen
3~4
Nonmetal
Standard air
19~22
2000W
SS400
oxygen
13~16
High pressure air
2~4
High pressure nitrogen
2~3
SUS304
oxygen
8~9
High pressure air
8~9
High pressure nitrogen
6~7
A5052
Standard air
3~5
High pressure air
7~8
High pressure nitrogen
8~9
Nonmetal
Standard air
19~22
2600W
SS400
oxygen
16~17
High pressure air
3~5
High pressure nitrogen
3~4
SUS304
oxygen
13~16
High pressure air
9~10
High pressure nitrogen
8~9
A5052
Standard air
4~5
High pressure air
6~7
High pressure nitrogen
8~9
Nonmetal
Standard air
19~22
3200W
SS400
oxygen
20~25
High pressure air
3~6
High pressure nitrogen
2~5
SUS304
oxygen
13~15
High pressure air
13~15
High pressure nitrogen
13~15
A5052
Standard air
7~9
High pressure air
9~11
High pressure nitrogen
12~14
Nonmetal
Standard air
27~30
4200W
SS400
oxygen
26~29
High pressure air
4~7
High pressure nitrogen
2~5
SUS304
oxygen
12~15
High pressure air
15~18
High pressure nitrogen
15~18
A5052
Standard air
7~9
High pressure air
9~11
High pressure nitrogen
12~14
Nonmetal
Standard air
27~30
3、Function
NT series CO2 laser
NT-1000
NT-1500
NT-2000
NT-2600
NT-3200
NT-4200
NT-5200
Rated output power
1000W
1500W
2000W
2600W
3200W
4200W
5200W
Maximum output power
>1000W
>1500W
>2000W
>2600W
>3200W
>4200W
>5200W
Laser wavelength
10.6(UM)
Ultra strong pulse power
2.5 times rated output power
Adjustable range of laser power
20W~MAX
Long time laser power stability
Continuous wave 1%
Pattern
TEM00-01
Beam divergence angle
<1.3mrad
Beam diameter
14mm
16mm
19mm
Pointing stability
<0.15mrad
Linear polarization
45 degrees with the horizontal plane
Beam quality
<1.5
Operation mode
Continuous wave and pulse super strong pulse can be converted manually and manually.
Pulse frequency
CW-2khz
Laser working gas
He N2 CO2 purity99.996%
Laser working gas consumption
8L/hr
15L/hr
25L/hr
30L/hr
Power supply requirements
380V + 2% 50Hz 3 phase middle line ground line
Power consumption
8kVA
18kVA
20kVA
38kVA
45kVA
52kVA
60kVA
Semiconductor laser optical path indicator
Full series configuration
Programmable pulse generator
Steady flow ultra strong impulse function
Application scope
Cutting: welding of metal and non-metallic materials such as carbon steel, stainless steel, galvanized sheet, titanium alloy, aluminum, composite, acrylic, plexiglass, wood, etc.: deep penetration between the same metal and different metals (diamond saw and thin wall drill): fusion, alloying, phase change hardening, (heat treatment, etc.)
4、After sale service The company has mastered the advanced laser processing technology and technology in the world, thus leading the development of laser processing technology and the direction of industrial development in China. Our company will provide users with turnkey engineering of laser and CNC laser processing machine system, and provide a complete set of industrial laser solutions for your enterprises. Pre sale service：our company will provide the corresponding technical advice and complete set of equipment data from the user's point of view according to the user's needs, answer various questions raised by the user, consider assisting the user to market analysis of the CNC laser processing machine from the technical point of view, and provide the processing base for the user to visit and inspect the field. Service in the sale：provide the user with a full set of equipment operation instructions, on-site inspection of the user's processing site, according to the actual situation of the user to assist the user to plan and design production sites, water, electricity, gas and so on. Provide free training for users of equipment operators. Before delivery, the user's equipment operators are trained in basic laser theory, safety protection and simple operation. In the site of installation and commissioning, our technical personnel will carry out practical processing, daily maintenance and safety training for the user's equipment operators, and the specific training time, number of times, people. The number is entirely determined by the users, so that users can master the operation procedures as soon as possible and put them into full use. After sale service:the company adopts the global first class purchase mode, all the key parts are famous products of Germany, the United States and Japan. The products are manufactured in strict accordance with international standards and international laser industry production technology standards, so that product quality and product stability are guaranteed reliable. The whole set of equipment is installed and debugged at the site of the user. From the date of acceptance, the equipment is guaranteed for one year (the acceptance of the equipment is subject to the satisfactory products processed by the user), and free technical support is provided for the whole life. During the warranty period, the company annually sends unscheduled technicians to the user's on-site technical visits, routine maintenance and inspection of the equipment, the technical questions raised by the user and the further training of the user's operators (the number of times will be less than four times). At present, Nanjing Optics Valley notai laser has set up eight branches in the country and more than 100 offices throughout the country. (see the company's website "the connection mode between headquarters and branches"), the branch office is stationed in technical service engineers to provide free delivery, installation and commissioning services to customers and provide free equipment operation. Training: national joint guarantee, providing free maintenance service and software free upgrade service, free annual check
