Size d*p |
Width(mm) |
Radius of arch |
Test load |
MBL |
Elongation on test load |
Elongation on MBL |
Grade |
|
|
mm |
Min |
max |
mm |
Kn |
Kn |
% |
% |
|
|
10x40 |
12 |
34 |
1.9 |
85 |
110 |
1.4 |
12 |
B |
|
100 |
130 |
1.6 |
12 |
C |
||||
|
14x50 |
17 |
48 |
4 |
150 |
190 |
1.4 |
12 |
B |
|
200 |
250 |
1.6 |
12 |
C |
||||
|
18x64 |
21 |
60 |
6.6 |
260 |
320 |
1.4 |
12 |
B |
|
330 |
410 |
1.6 |
12 |
C |
||||
|
22x86 |
26 |
74 |
9.5 |
380 |
480 |
1.4 |
12 |
B |
|
490 |
610 |
1.6 |
12 |
C |
||||
|
26x92 |
30 |
86 |
13.7 |
540 |
670 |
1.4 |
12 |
B |
|
690 |
850 |
1.6 |
12 |
C |
||||
|
30x108 |
34 |
98 |
18 |
710 |
890 |
1.4 |
12 |
B |
|
900 |
1130 |
1.6 |
12 |
C |
||||
|
34x126 |
38 |
109 |
22.7 |
900 |
1140 |
1.4 |
12 |
B |
|
1160 |
1450 |
1.6 |
12 |
C |
||||
|
38x137 |
42 |
123 |
29 |
1450 |
1810 |
1.6 |
12 |
C |
|
42 |
110 |
|||||||
|
42x146 |
46 |
135 |
35.3 |
1770 |
2220 |
1.6 |
12 |
C |
|
46 |
115 |
|||||||
|
No. Size and mechanical properties(grade B) |
|||||||||
|
No. |
Size |
Width(mm) |
r |
Unit weight |
Test load |
Elongation on test load |
MBL |
Elongation on MBL |
|
|
|
mm |
Min |
max |
Mm |
Kg/m |
Kn |
% |
kn |
% |
|
SL2210540/370 |
22x105 |
40 |
87 |
41 |
2.9 |
70 |
2 |
370 |
15 |
|
SL2611846/520 |
26x118 |
46 |
102 |
48 |
4.6 |
100 |
2 |
520 |
15 |
|
SL2812048/610 |
28x120 |
48 |
108 |
51 |
6.7 |
110 |
2 |
610 |
15 |
|
SL3012048/670 |
30x120 |
48 |
112 |
53 |
7.8 |
120 |
2 |
670 |
15 |
|
SL3013055/670 |
30x130 |
55 |
119 |
56.5 |
6.9 |
120 |
2 |
670 |
15 |
|
SL3214058/790 |
32x140 |
58 |
126 |
60 |
9.9 |
140 |
2 |
790 |
15 |
|
SL3414764/890 |
34x147 |
64 |
136 |
65 |
10.1 |
160 |
2 |
890 |
15 |
|
SL3814580/1110 |
38x145 |
80 |
160 |
77 |
13.65 |
200 |
2 |
1110 |
15 |
Welcome to consult China Mining Chains suppliers. We have more than 10 years of foreign trade supply experience and have provided high-quality shipping equipment to dozens of countries around the world. We provide you with high-quality services and preferential prices customized by manufacturers. You can get a free quote online or leave a message below and we will reply to you within 24 hours.
