Winches have the following characteristics: high versatility, compact structure, small size, light weight, heavy lifting, easy to use and transfer. They are widely used in building, water conservancy engineering, forestry, mining, wharf and other materials lifting or flat towing, and can also be used as supporting equipment for modern electronic control automatic operation line. There are 0.5 tons to 350 tons, divided into fast and slow two kinds. The winch above 20 tons is a large-tonnage winch, which can be used alone or as a component of lifting, road building and mine hoisting machinery. It is widely used because of its simple operation, large rope winding and convenient displacement. The main technical indexes of winch are rated load, support load, rope speed, rope capacity, etc.
Main uses of winch: First, as lifting equipment, it is used for mine hoisting, sinking hoisting and hanging (lifting) sinking equipment facilities, that is, lifting ore, waste (gangue), lifting personnel, materials, tools and equipment along the shaft, etc.
|
tem |
Specification & Technical Parameter |
|||||
|
Model |
JQHS-20 *18 |
JQHS-30* 12 |
JQHS-50* 12 |
JQHS-100* 8 |
JQH-5* 48 |
JQH-10* 24 |
|
Rated Pulling |
20KN |
30KN |
50KN |
100KN |
5KN |
10KN |
|
The maximum speed |
18m/min |
12m/min |
12m/min |
8m/min |
48m/min |
24m/min |
|
Rated Power |
5.6kw |
12kw |
16kw |
30kw |
2.6kw |
3.6kw |
|
Rated Intake Air |
0.6Mpa |
0.6Mpa |
0.6Mpa |
0.6Mpa |
0.6Mpa |
0.6Mpa |
|
Rated Air |
5m3/min |
10m3/min |
12.7m3/min |
24m3/min |
2.0m3/min |
2.3m3/min |
|
Rope capacity |
100m |
200m/400m |
200m/400m |
200m |
80m |
80m |
|
The diameter of |
12mm |
16mm |
18.5mm |
24mm |
8mm |
10mm |
|
Overall size |
560* 360* 460mm |
1250* 500* 700mm |
1300* 520* 760mm |
1500* 720* 920mm |
560* 360* 420mm |
590*380* 460mm |
|
Weight |
200kg |
500kg |
550kg |
1100kg |
130kg |
160kg |
Welcome to consult China Pneumatic Air Winch suppliers. We have more than 10 years of foreign trade supply experience and have provided high-quality shipping equipment to dozens of countries around the world. We provide you with high-quality services and preferential prices customized by manufacturers. You can get a free quote online or leave a message below and we will reply to you within 24 hours.
