The solid float PVC boom is an economical, universal boom for intercepting oil spills and other floats on waters. It is suitable for the permanent, stationary deployment on waters. Fast deployment and easy operation.
It is widely used on rivers, harbors, lakes, offshore oil platforms and other waters.
Made of high strength fabric coated with orange PVC on its two sides, having excellent resistance to oil and aging.
The solid float have a large capacity of buoyancy and excellent wave riding and steadiness.
The boom body is provided with a pulling rope, a strengthening ribbon and tensile ballast chains serving as elements to withstand forces and has high tensile strength.
| Model | WGV600 | WGV700 | WGV750 | WGV800 | WGV900 | WGV1000 | WGV1100 | WGV1500 |
| Overall height(mm) | 600 | 700 | 750 | 800 | 900 | 1000 | 1100 | 1500 |
| Freeboard(mm) | 150 | 210 | 260 | 280 | 320 | 340 | 370 | 520 |
| Draft(mm) | 380 | 390 | 400 | 420 | 490 | 540 | 560 | 760 |
| Length per section(m) | 20 | |||||||
| max.working tensile strength(Kn) | 20 | 25 | 30 | 45 | 55 | 75 | 85 | 130 |
| Max.Wave height to withstand(m) | 0.5 | 0.5 | 1 | 1.5 | 1.8 | 2 | 2 | 3 |
| Max.wind speed to withstand(m/s) | 8 | 10 | 10 | 15 | 15 | 18 | 20 | 20 |
| Max.Current speed to withstand(knot) | 1 | 1 | 1.5 | 1.5 | 2 | 2.5 | 2.5 | 3 |
| Packing dimensions for 20m(m) | 1*1*0.3 | 1.2*1*1 | 1.1*1*1 | 1.3*1*1 | 1.4*1.5*1.2 | 1.4*1.6*1.3 | 1.4*1.7*1.4 | 1.6*1.9*1.8 |
Welcome to consult China Solid Float PVC Boom suppliers. We have more than 10 years of foreign trade supply experience and have provided high-quality shipping equipment to dozens of countries around the world. We provide you with high-quality services and preferential prices customized by manufacturers. You can get a free quote online or leave a message below and we will reply to you within 24 hours.
